SD Series Plastic Extruders
SJ Series Venting Type Single Screw Extruder
The special design of the air venting type extruder, effectively overcomes the shortages during the plastic processing course, greatly increases the product quality. Therefore it is a very suitable extruder to produce PMMA, PC, PS, PET products which have high quality requirement.
Drop us a line
Detail
The special design of the air venting type extruder, effectively overcomes the shortages during the plastic processing course, greatly increases the product quality. Therefore it is a very suitable extruder to produce PMMA, PC, PS, PET products which have high quality requirement.
Model | SJ-45 | SJ-60 | SJ-65 | SJ-75 | SJ-90 | SJ-100 | SJ-120 | SJ-130 | SJ-150 | SJ-165 |
Transmission power (kw) | 15~22 | 22~37 | 30~45 | 45 | 55~90 | 75~110 | 132~185 | 185~280 | 185~315 | 220~355 |
Screw diameter(mm) | 40 | 60 | 65 | 75 | 90 | 100 | 120 | 130 | 150 | 165 |
Screw L/D ratio | 35 | 35 | 35 | 35 | 35 | 35,38 | 35,38 | 35,41 | 35 | 35 |
Screw rotation speed r/min | 120 | 120 | 100 | 100 | 90 | 90 | 90 | 90 | 80 | 80 |
Extrusion capacity kg/h | 15~45 | 60~100 | 60~120 | 60~150 | 150~280 | 180~350 | 250~450 | 300~650 | 400~600 | 550~700 |
